What is SWG

SASE?, SSE?, SWG is subset of SSE for security.

1. Requirements

Functional

1. Filtering and monitoring web traffic to enforce security policies
2. URL Filtering: Some URLs are marked as filtered and policies are enforced on their access.
3. Web Traffic Filtering: Inspect/filter web traffic in real-time, allow/block access to websites based on predefined security policies.
4. Malware and Threat Protection: Scan & block web content for malware, viruses, and other malicious code.
5. Data Loss Prevention (DLP): Enforce DLP policies to prevent sensitive data from being leaked or shared.
6. SSL/TLS Inspection: SWGs can decrypt and inspect encrypted web traffic to detect threats hidden within encrypted connections. This is crucial as many threats now use encryption to evade detection.
7. User Authentication: Integrate with identity and access management systems to enforce security policies based on user roles and permissions.
8. Reporting and Analytics: Generate reports and provide insights into web usage patterns and security incidents.
9. Cloud-Based or On-Premises: Can be deployed in the cloud/on-premises, or as hybrid solution, depending on an organization’s requirements and preferences.
10. Mobile Device Support: Protect mobile devices, ensuring that users are secured even when they access the internet from smartphones and tablets.
11. Anomaly detection:

Non Functional

Scalable, Reliable, Fast, Highly available

3. Databases & Events

Databases

Database Stores
MySQL 1. Cust-Public,pvt keys are stored in HSM(Hardware security module): When tenant is onboarded, Cert hierarchy is created. All keys, certs, signatures stored here.
2. All tenant data
3. Storing meta data for Druid cluster
Redis (key/value store) Generic task queing and task broker(Apart from kafka, when all nodes are not prod,cons)
Mongodb Events which are fed to kafka are stored here and it acts as source of truth

Event Pipeline/Message Buses

1. Kafka: Event Producers: Services. Services reach Evt-Svc, which puts events in kafka & also into mongodb
Events Consumers: Druid OLAP
2. Zero MQ: In memory fast storage, high performance. Whereas kafka is persistant datasource

Metadata of Distributed Systems

Zookeeper

Observability

Sumologic, Datadog(Bit inexpensive wrt sumo), SignalFX(Best solution for scaling the app), ELK(Druid Logging)

Load Balancing

ngnix, haproxy, F5

4. HLD

srx authentication table
